1. RFID UHF Distributor Demo Kit
$990.00
Complete RFID UHF Demonstration Kit for Distributors and System Integrators
Fully functional hardware and software demonstration package for testing RFID UHF access control, anti-theft, inventory management, asset tracking and system integration workflows.
🇺🇸 IN STOCK IN THE USA
- ✓ F-930 RFID UHF reader — 1 pc.
- ✓ F-02 USB tag encoder / writer — 1 pc.
- ✓ RFID UHF sample tags — 20 pcs.
- ✓ Red flashing light with adjustable audible alarm
- ✓ Power supply and mounting bracket
- ✓ Anti-Theft / Inventory demo software
- ✓ Access Control demo software
- ✓ Factory / Warehouse demo software
- ✓ TCP/IP and RS232 communication
Demonstration use only.
This is a fully functional demonstration system intended for evaluation, training, sales demonstrations, software testing and system-integration testing. It is not intended as a commercial production deployment package.
Optional: Wi-Fi, PoE and wireless SMS / phone / smartphone alarm notifications can be added depending on the demonstration requirements.
Description
Fresh USA RFID UHF Distributor Demo Kit
Complete working RFID UHF demonstration system for distributors, developers, installers and system integrators who need to evaluate Fresh USA hardware, tags and software before designing or presenting a commercial RFID solution.
Complete RFID UHF Demonstration System
The Fresh USA Distributor Demo Kit combines a compatible RFID UHF reader, tag programming equipment, sample tags, alarm hardware and demonstration software in one working package.
The kit can be used to demonstrate and test several different system concepts without purchasing separate demonstration hardware for each application.
Typical demonstration workflows include:
- ✓ Vehicle and gate access control
- ✓ Authorized credential recognition
- ✓ Anti-theft exit detection
- ✓ Inventory management
- ✓ Asset and equipment tracking
- ✓ Warehouse and factory tracking workflows
- ✓ RFID tag programming and testing
- ✓ Reader-to-software communication
- ✓ Relay integration with external equipment
What Is Included
| Component | Qty. | Purpose |
|---|---|---|
| F-930 RFID UHF Reader | 1 | Main RFID UHF detection and communication unit with TCP/IP and RS232 connectivity. |
| Red Flashing Light / Alarm | 1 | Visual and audible demonstration alarm. Sound level adjustable up to approximately 105 dB and can be turned off when required. |
| Power Supply | 1 | 110–220V AC input to 9V DC output for the reader system. |
| Mounting Bracket | 1 | Bracket for mounting and positioning the reader during demonstrations and testing. |
| F-02 USB Tag Encoder / Writer | 1 | Used to program compatible RFID UHF tags and credentials for demonstration applications. |
| RFID UHF Sample Tags | 20 | Sample tags for testing tag programming, recognition, detection and software workflows. |
| Demo Software Package | Included | Demonstration versions of Fresh USA software for one Windows computer. |
✓ One Kit — Multiple RFID Demonstrations
The same demonstration hardware can be used to show different Fresh USA concepts by changing the software configuration, tags and connected external equipment.
This makes the kit suitable for distributors and system integrators who need one portable platform for product demonstrations, customer presentations, technical testing and proof-of-concept work.
Included Demo Software
The Distributor Demo Kit includes demonstration software for one Windows computer so that several Fresh USA application types can be tested with the included hardware.
| Demo Software | Demonstration Applications |
|---|---|
| Anti-Theft / Inventory Software | Tagged-item detection, anti-theft event testing, inventory records and related inventory workflows. |
| Access Control Software | Credential recognition, access-control demonstrations, parking / gate concepts and reader-to-software communication. |
| Factory / Warehouse Software | Inventory, asset identification, location and movement tracking demonstrations. |
→ View Anti-Theft / Inventory Software
→ View Access Control Software
→ View Factory / Warehouse Inventory and Asset Tracking Software
Important — Demo licenses are not commercial production licenses.
The software supplied with this kit is intended for demonstration, evaluation, training and technical testing. Commercial customer installations and production deployments require the appropriate Fresh USA commercial software, reader licenses and project-specific equipment.
F-930 RFID UHF Reader
The included reader provides the main RFID UHF detection platform for the demonstration system.
| Technology | RFID UHF |
|---|---|
| Frequency | 860–960 MHz |
| Communication | TCP/IP and RS232 |
| Relay Operation | Can provide a control signal for compatible external alarm or access-control equipment. |
→ View F-930 Reader Technical Information
F-02 USB Tag Encoder / Writer
The included F-02 can be used to program compatible RFID UHF tags and credentials for access-control, inventory, demonstration and testing workflows.
This allows a distributor or integrator to demonstrate the complete process:
Program Tag → Register Tag → Detect Tag → Process Event → Trigger Software or Relay Action
→ View F-02 Technical Information
Standalone Authorized-Tag Demonstration
The reader can also be demonstrated in standalone operation using pre-programmed authorized RFID UHF tags.
In this mode, the reader recognizes the authorized tag code and activates its relay output when the configured conditions are met.
The relay can be connected to compatible external equipment such as:
- ✓ Alarm or warning device
- ✓ Gate operator control input
- ✓ Barrier-arm controller
- ✓ Door access controller
- ✓ Turnstile control input
- ✓ Other compatible dry-contact control inputs
This provides an IFF-like authorization concept: an authorized credential is recognized and the configured output action is triggered.
External equipment must provide a compatible control input.
The reader relay is intended to provide a control signal. It should not directly power gate motors, locks, barrier motors or other high-current equipment.
Optional Add-Ons
The demonstration system can be expanded when additional communication or alarm-notification functions are required.
| Option | Function |
|---|---|
| Wi-Fi | Optional wireless network communication depending on system configuration. |
| PoE Module | Optional Power-over-Ethernet configuration for compatible installations. |
| Wireless Alarm Notification System | Optional GSM 4G / Wi-Fi notifications by SMS, phone call and smartphone application. |
→ View Wireless Alarm Notification System
Who Is This Demo Kit For?
- ✓ Fresh USA distributors
- ✓ RFID system integrators
- ✓ Access-control installers
- ✓ Security-system integrators
- ✓ Software developers
- ✓ Automation companies
- ✓ Technical sales teams
- ✓ Businesses evaluating RFID UHF technology
- ✓ Organizations building proof-of-concept systems
What Can Be Demonstrated?
| Application | Example Demonstration |
|---|---|
| Access Control | Register a credential, recognize it at the reader and trigger a compatible access-control relay input. |
| Parking / Vehicle Access | Demonstrate long-range credential recognition and integration with a compatible gate or barrier control input. |
| Anti-Theft | Detect tagged merchandise or assets and demonstrate local visual / audible alarm operation. |
| Inventory | Register tags, identify tagged items and demonstrate inventory software workflows. |
| Asset Tracking | Associate tagged assets with reader locations and demonstrate movement or detection records. |
| Tag Programming | Program compatible tags using the included F-02 encoder and test them with the reader. |
Demo Kit vs. Commercial Deployment
| Use | Distributor Demo Kit | Commercial System |
|---|---|---|
| Product demonstrations | ✓ Yes | Possible, but not the intended purpose |
| Training and testing | ✓ Yes | Project dependent |
| Proof of concept | ✓ Yes | Final system follows approved project design |
| Customer production deployment | No | ✓ Yes |
| Commercial software licenses | Demo licenses | Required according to system configuration |
Package Information
| Package Weight | Approximately 12 lb |
|---|---|
| Package Dimensions | Approximately 24 × 20 × 5 in |
Shipping and Taxes
USPS is the standard shipping service for this demo kit. If another carrier is requested, alternate shipping can be arranged at the buyer’s expense.
Taxes, customs charges, import duties and other destination-country fees are not included unless specifically stated in the order.
Before ordering for international delivery
The purchaser is responsible for confirming local import requirements, customs procedures and any applicable duties or taxes at the destination.
Frequently Asked Questions
Is this a complete working system?
Yes. The Distributor Demo Kit is a working demonstration system that includes reader hardware, tag programming equipment, sample RFID UHF tags and demonstration software.
Can I use this kit for a commercial customer installation?
No. The Distributor Demo Kit is intended for demonstrations, evaluation, training, proof-of-concept work and technical testing. Commercial deployments require the appropriate production hardware and commercial software / reader licenses.
Which reader is included?
The kit includes one Fresh USA F-930 RFID UHF reader with TCP/IP and RS232 communication.
Is a tag encoder included?
Yes. One Fresh USA F-02 USB RFID UHF tag encoder / writer is included.
Are RFID tags included?
Yes. The kit includes a 20-piece RFID UHF sample tag pack for demonstration and testing.
Can I test standalone operation?
Yes. Pre-programmed authorized tags can be used to demonstrate standalone recognition and relay activation without using the Windows software for every access event.
Can I test software-managed operation?
Yes. Demonstration software is included for access control, anti-theft / inventory and factory / warehouse workflows.
Can the reader operate a gate or barrier?
The reader relay can provide a control signal to compatible gate, barrier, door or access-control equipment. The external equipment must provide the appropriate control input.
Is Wi-Fi included?
Wi-Fi is optional and depends on the required demonstration configuration.
Can PoE be added?
Yes. A compatible PoE module can be added when required.
Can I receive SMS or phone notifications?
Yes. The optional Wireless Alarm Notification System can provide SMS, phone-call and smartphone-app notifications using GSM 4G and / or Wi-Fi connectivity.
Can I use different RFID UHF tag types?
Yes. Tag selection depends on the material, orientation, mounting method and required detection distance. Additional compatible RFID UHF tag types can be purchased separately for testing.
Need a Demo Kit for a Specific Application?
Tell Fresh USA what you want to demonstrate — access control, parking, anti-theft, inventory management, asset tracking, warehouse operations or another RFID UHF workflow.
We can help determine which optional communication modules, alarm accessories and additional tag samples are appropriate for your demonstration.
Phone: +1 (312) 312-9608
Additional information
| Weight | 12 lbs |
|---|---|
| Dimensions | 24 × 20 × 5 in |
